Main Description Of The Product：

1. 180°Tooless unshielded KJ. The products are used in the equipment rooms & work
 area as communication connectors of the intelligent buildings.                                              2. The structure of the Keystone Jack is compact and tooless. This design is based on
 contemporaneity aesthetics. The original dust free tooless punching hats can make
 your work more easy and fast, and it can also prevent the cable to break off from
 the IDC ports.                                                                                                                              3.   According to the standard of ISO/IEC 11801:2002 Class E & ANSI/TIA/EIA 568-B.2-1 CAT.6 standard.                                                                                                                                      4.  Connecting: RJ45 port for STP patch cord and the IDC port for STP horizontal cabling. 5.  In accordance with RoHS derective.                                                                                          6.  Fitting for Cat.6 cabling systems, can also be used on Cat.5 and Cat.5e cabling
systems.

Technique Characteristics：

1.  Material of plastic parts: PC UL94V-0                                                                                        2.   8 Pin of the RJ45 jack: Phosphor bronze with golden plated 3U、6U、15U、30U、50U at option. Inserting duration: 750 times.                                                                       3.  IDC Clips: Tinned phosphor bronze pins. Fitting for 22AWG/23AWG/24AWG cables. Punching duration: 250 times.                                                                                                        4.  Punching tool: tooless type.                                                                                                  5.  Testing condition of transmitting capability: 250MHz
