Range of Products >>Telecommunication  >> Keystone Jack  >>  N-4029











Main Description Of The Product:

1.  Unshielded Keystone jack. Tooless type, The products are used in the equipment
 rooms & work area as communication connectors of the intelligent buildings.                   2.   According to the standard of ISO/IEC 11801:2002 Class E & ANSI/TIA/EIA 568-B.2-1 CAT.6 standard.
3.  According the requirement of T568A & T568B. The T568A & T568B labels are sticked
 on the both sides of the product to give a exact guide when a engineer punches the cables.                                                                                                                                            4.  Connecting: RJ45 port for UTP patch cord and the IDC port for UTP horizontal cabling. 5.  In accordance with RoHS directive.                                                                                           6.  Fitting for Cat.6 cabling systems, can also be used on Cat.5 and Cat.5e cabling
systems.

Technique Characteristics:

1.  Material of plastic parts: PC UL94V-0                                                                                        2.   8 Pin of the RJ45 jack: Phosphor bronze with golden plated 3U、6U、15U、30U、50U at option. Inserting duration: 750 times.                                                                       3.  IDC Clips: Tinned phosphor bronze pins. Fitting for 22AWG/23AWG/24AWG cables. Punching duration: 250 times.                                                                                                        4.  Punching tool: tooless type.                                                                                                  5.  Testing condition of transmitting capability: 250MHz
