Main Description Of The Product:
1. Unshielded
KJ. The products are used in the equipment rooms &
work area as
communication connectors of the intelligent
buildings.
2. The
structure of the Keystone Jack is compact, that can
make your work more easy
and fast. The original dust-free cap can prevent the
cable from slipping off from the IDC ports.
3. According
to the standard of ISO/IEC 11801:2002 Class E &
ANSI/TIA/EIA 568-B.2-1 CAT.6 standard.
4. According
the regnirement of T568A & T568B. The T568A & T568B
labels are sticked
on the both sides of the product to give a exact
guide when a engineer punches the cables.
5. Connecting: RJ45 port for UTP patch
cord and the IDC port for UTP horizontal cabling.
6. In
accordance with RoHS derective.
7. Fitting
for Cat.6 cabling systems, can also be used on Cat.5
and Cat.5e cabling
systems.
Technique Characteristics:
1. Material of plastic parts: PC
UL94V-0
2. 8 Pin
of the RJ45 jack: Phosphor bronze with golden plated
3U、6U、15U、30U、50U at option. Inserting duration: 750
times. 3. IDC
Clips: Tinned phosphor bronze pins. Fitting for
22AWG/23AWG/24AWG cables. Punching duration: 250
times.
4.
Punching tool: Standard 110 punching tool.
5. Testing condition of transmitting capability:
250MHz |
