1.  Voltage rating: 125 VAC RMS                                                                                                                             2.  Current rating: 1.5 AMP                                                                                                                                         3.  Contact resistance: 100 Milliohms MAX                                                                                                    4.  Insulation resistance: 1000 Megohms MIN @ 500 VDC                                                                           5.  Dielectric strength: 750 VAC RMS 60Hz, 1MIN

ENVIRONMENTAL：

1.  Storage: -40°TO +85°                                                                                                                                       2.  Operation: 0° TO 70° Conform to TIA/EIA 568B Category                                                                                      3.  Mates with modular plug conforming to FCC part 68, Subpart F.

MECHANICAL：

1.  Housing material: PC UL94V-0                                                                                                                       2.  Insert material: Flame retardancy ABS UL94V-0                                                                                                  3.  PCB material: FR-4   Thickness:1.6mm                                                                                                                   4.  Contact material: Phosphor bronze stamp PIN T=0.35mm                                                                               5.  IDC Contact material: Phosphor bronze T=0.50mm with nickel plating                                                        6.  Wire: AWG 24-26
