Standard |
UL
|
VDE
|
Rated voltage |
300V
|
250V
|
Rated current |
8A
|
7A
|
Wire range |
28-16AWG
|
0.5-1.5mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
7mm
|
Pitch |
3.50 / 3.81 mm(.150")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PA66,UL94V-0
|
Contact |
Brass, Ni plated
|
Wire Guard |
Stainless Steel
|
|
|
