Standard |
UL
|
CE
|
Rated voltage |
300V
|
750V
|
Rated current |
55A
|
57A
|
Wire range |
12-6AWG
|
4.0-10.0mm2
|
Withstanding
voltage |
AC3000V/1Min
|
Torque |
2.0Nm(10.6Lb-In.) |
Ambient
temperature |
-40°C~+105°C
|
Pitch |
19.0mm (.295")
|
Poles |
1P
|
Housing |
PA66,UL94V-0
|
Screws |
M5.0,steel,Cr3+ Zn
plated |
Terminals |
Brass, Tin-Plated
|
|
|
