Standard |
UL
|
CE
|
Rated voltage |
300V
|
250V
|
Rated current |
10A
|
24A
|
Wire range |
24-14AWG
|
0.5-2.5mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Torque |
0.5Nm(10.5Lb-In.) |
Ambient
temperature |
-40°C~+105°C
|
Pitch |
7.50mm (.295")
|
Poles |
02P / 03P
|
Housing |
PA66,UL94V-0
|
Screws |
M3.0,steel,Cr3+ Zn
plated |
Terminals |
Brass, Tin-Plated
|
|
|
