Standard |
UL
|
CE
|
Rated voltage |
300V
|
250V
|
Rated current |
20A
|
32A
|
Wire range |
12-20AWG
|
0.75-4.0mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Torque |
1.2Nm(10.5Lb-In.) |
Ambient
temperature |
-40°C~+105°C
|
Pitch |
12.50mm (.295")
|
Poles |
01P
|
Housing |
PA66,UL94V-0
|
Screws |
M4.0,steel,Cr3+ Zn
plated |
Terminals |
Brass,Tin-Plated
|
|
|
