Standard |
UL
|
CE
|
Rated voltage |
300V
|
750V
|
Rated current |
20A
|
41A
|
Wire range |
20-10AWG
|
0.5-6.0mm2
|
Withstanding
voltage |
AC3000V/1Min
|
Torque |
1.2Nm(10.6Lb-In.) |
Ambient
temperature |
-40°C~+105°C
|
Pitch |
7.50mm (.295")
|
Poles |
1P ,2P
|
Housing |
PA66,UL94V-0
|
Screws |
M4.0,steel,Cr3+ Zn
plated |
Terminals |
Brass, Ni-Plated
|
|
|
