Standard |
UL
|
IEC
|
Rated
voltage |
150V
|
130V
|
Rated
current |
2A
|
6A
|
Wire
range |
24-20AWG
|
0.2-1.0mm2
|
Withstanding voltage |
AC1250V/1Min
|
Ambient temperature |
-40°C~+105°C
|
Strip
length |
11mm
|
Pitch |
2.54 / 2.50mm(.100")
|
Poles |
1P-XXP
|
Housing |
PA66+5%GF.,UL94V-0
|
Pin
header |
Brass,Tin plated
|
Wire
guard |
Stainless steel
|
|
|
