| Standard |
UL
|
IEC
|
| Rated voltage |
150V
|
130V
|
| Rated current |
2A
|
6A
|
| Wire range |
24-20AWG
|
0.2-1.0mm2
|
| Withstanding
voltage |
AC1250V/1Min
|
| Ambient
temperature |
-40°C~+105°C
|
| Strip length |
11mm
|
| Pitch |
2.54mm(.100")
|
| Poles |
1P-XXP
|
| Housing |
PA66+5%GF.,UL94V-0
|
| Pin header |
Brass,Tin plated
|
| Wire guard |
Stainless steel
|
|
|
