Standard |
UL
|
IEC
|
Rated voltage |
300V
|
250V
|
Rated current |
5A
|
15A
|
Wire range |
20-18AWG
|
0.2-2.5mm2
|
Withstanding
voltage |
AC1250V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
9-10mm
|
Pitch |
3.50/3.81/ 5.00 / 5.08mm(.100")
|
Poles |
1P-XXP
|
Housing |
PA66+5%GF.,UL94V-0
|
Pin header |
Brass,Tin plated
|
Wire guard |
Stainless steel
|
|
|
