Standard |
UL
|
VDE
|
Rated voltage |
300V
|
250V
|
Rated current |
10A
|
12A
|
Wire range |
24-12AWG
|
2.5mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
5-6mm
|
Torque |
0.4Nm(4.4Lb-In.) |
Pitch |
5.00 / 10.00 mm(.100")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PA66,UL94V-0
|
Screws |
M2.5,steel,Cr3+
Zn plated |
Contact |
Phosphor Bronze
|
Wire Cage |
Brass, Ni Plated
|
|
|
