| Standard |
UL
|
CE
|
| Rated voltage |
300V
|
250V
|
| Rated current |
30A
|
32A
|
| Wire range |
22-12AWG
|
4.0mm2
|
| Withstanding
voltage |
AC2000V/1Min
|
| Torque |
1.2Nm(10.6Lb-In.) |
| Ambient
temperature |
-40°C~+80°C
|
| Pitch |
13.50mm (.295")
|
| Poles |
3P
|
| Housing |
PC,UL94V-0
|
| Screws |
M4.0,steel,Cr3+ Gold
plated |
| Terminals |
Brass, Gold-Plated
|
|
|
