Standard |
UL |
CE |
Rated
voltage |
300V |
250V |
Rated
current |
30A |
40A |
Wire range |
18-10AWG |
6.0mm2 |
Withstanding voltage |
AC2000V/1Min |
Torque |
1.2Nm(10.6Lb-In.) |
Ambient
temperature |
-40°C~+80°C |
Pitch |
11.00mm
(.295") |
Poles |
2P --11P |
Housing |
PC,UL94V-0 |
Screws |
M4.0,steel,Cr3+ Gold plated |
Terminals |
Brass,
Gold-Plated |
|
|
