Standard |
UL
|
VDE
|
Rated voltage |
300V
|
750V
|
Rated current |
52A
|
57A
|
Wire range |
20-6AWG
|
10.0mm2
|
Withstanding
voltage |
AC3000V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
4.5mm
|
Torque |
1.2Nm(10.5Lb-In.) |
Pitch |
10.16 mm(.197")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PA66,UL94V-0
|
Screws |
M4,steel,Cr3+
Zn plated |
Solder Pins |
Brass, Tin plated
|
Contact Cage |
Brass, Ni plated
|
|
|
