Standard |
UL
|
VDE
|
Rated voltage |
300V
|
250V
|
Rated current |
20A
|
20A
|
Wire range |
26-12AWG
|
2.5mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
7mm
|
Torque |
0.5Nm(3.5Lb-In.) |
Pitch |
5.00 / 5.08mm(.197")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PA66,UL94V-0
|
Screws |
M3,steel,Cr3+
Zn plated |
Solder Pins |
Brass, Tin plated
|
Contact Cage |
Brass, Ni plated
|
|
|
