Range of Products >>Terminal Block >> Screw Clamp TB  >>  GS026L







Standard
UL
VDE
Rated voltage
300V
250V
Rated current
15A
24A
Wire range
28-12AWG
0.5--2.5mm2
Withstanding voltage
AC2000V/1Min
Ambient temperature
-40°C~+105°C
Strip length
7mm
Torque 0.4Nm(3.5Lb-In.)
Pitch
5.00 (.197")
Poles
2P , 20P ---Any poles
Housing
PA66,UL94V-0
Screws

M2.5,steel,Cr3+ Zn plated

Contact Pin
Brass, Tin plated







  How To Order: :

GS026L

5.00

02 P

4



A


Series No.   Pitch(mm)   No.of Poles   Color   Screw Type A: Slot "-"
    5.00

1. Grey     2.Blue

B. Crossing "+"



3. Black   4.Green




5.Orange   6.Red








7.Natural   8.White
