Standard |
UL
|
VDE
|
Rated voltage |
300V
|
450V
|
Rated current |
20A
|
24A
|
Wire range |
22-14AWG
|
2.5mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Ambient
temperature |
-30°C~+120°C
|
Strip length |
5--6mm
|
Torque |
0.5Nm(4.4Lb-In.) |
Pitch |
5.00 / 10.00 mm(.100")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PC,UL94V-0
|
Screws |
M3.0,steel,Cr3+
Zn plated |
Contact |
Brass,Tin plated
|
Wire guard |
Stainless steel
|
|
|
|
How
To Order: : |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GS023 |
– |
5.00 |
– |
02 |
P |
– |
1 |
– |
|
|
Series No. |
|
Pitch(mm) |
|
No.of Poles |
|
Color |
|
Customer Request |
|
|
5.00 |
|
|
|
|
1. Grey
2.Blue |
|
|
|
10.00 |
|
|
|
|
3. Black 4.Green |
|
|
|
|
|
|
|
|
5.Orange 6.Red |
|
|
|
|
|
|
|
|
7.Natural 8.White |
|
PS: This
parts used of PC Materials,can stand very high
temprature and good
characteristics |
|
|
|
