Standard |
UL
|
VDE
|
Rated voltage |
300V
|
250V
|
Rated current |
15A
|
22A
|
Wire range |
22-12AWG
|
0.5-2.5mm2
|
Withstanding
voltage |
AC2000V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
6-7mm
|
Torque |
0.6Nm(4.4Lb-In.) |
Pitch |
5.00 mm(.197")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PA66,UL94V-0
|
Screws |
M3,steel,Cr3+
Zn plated |
Contact |
Brass,Tin plated
|
Wire guard |
Stainless steel
|
|
|
