Standard |
UL
|
VDE
|
Rated voltage |
150V
|
130V
|
Rated current |
6A
|
8A
|
Wire range |
26-18AWG
|
1.0mm2
|
Withstanding
voltage |
AC125V/1Min
|
Ambient
temperature |
-40°C~+105°C
|
Strip length |
4.5mm
|
Torque |
0.1Nm(0.89Lb-In.) |
Pitch |
2.54 mm(.197")
|
Poles |
2P , 3P ---Any poles
|
Housing |
PA66,UL94V-0
|
Screws |
M1.6,steel,Cr3+
Zn plated |
Solder Pins |
Brass, Tin plated
|
Contact Cage |
Brass, Ni plated
|
|
|
