Contact Resistance |
20 mΩ ,max. at DC
100mA
|
Insulator Resistance |
1000 mΩ ,min. at DC
500V
|
Current Rating |
3 AMP
|
Withstanding voltage |
AC1000V/1Min
|
Operating temperature |
-40°C~+105°C
|
Contact |
Brass
|
Housing |
PBT & 30% Glass
Fiber(UL94V-0)
|
|
|
|
|
|
|
How to Order: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DK901 |
– |
20 |
|
S |
|
G |
|
Series No. |
|
Poles |
|
Type Option |
G:
Gold Plated |
|
|
|
|
S: Single Row Type |
T: Tin Plated |
|
|
|
|
D: Double Row Type |
|
|
|
|
|
