Contact Resistance |
20 mΩ ,max. at DC 100mA
|
Insulator Resistance |
1000 mΩ ,min. at DC 500V
|
Current Rating |
40AMP
|
Withstanding voltage |
AC500V/1Min
|
Operating
temperature |
-45°C~+110°C
|
Contact |
Brass or Phosphor Bronze
|
Housing |
PBT & 30% Glass Fiber(UL94V-0)
|
|
|
|
How
To Order: : |
|
|
|
|
|
|
|
|
|
|
|
|
|
DS1038-02 |
– |
15 |
|
F |
– |
B |
– |
S |
Series No. |
|
No of Poles |
|
F: Female |
|
Color |
|
S: Standard |
|
|
15 , 26 , 44 |
|
M: Male |
|
B. Blue |
C: CC Type |
|
|
|
|
|
|
K. Black |
|
|
|
|
|
|
|
W. White |
|
|
|
|
