Range of Products >> Connector  >> D-sub Series >>  DHR







Contact Resistance
30 mΩ ,max. at DC 100mA
Insulator Resistance
1000 mΩ ,min. at DC 500V
Current Rating
5AMP
Withstanding voltage
AC1000V/1Min
Operating temperature
-55°C~+105°C
Contact
Brass or Phosphor Bronze
Housing
PBT & 30% Glass Fiber(UL94V-0)












  How to Order:

DHR 15   F B B
Series No.   No.of Poles Item Type   Foot Print   Color   Customer Request
     15P / 26P   F: Female   B: 3.08MM   B. Blue
     44P / 62P   M: Male   D: 9.40MM   K. Black
              W. White
